los aluminum sheet size depends entirely on its thickness, anchura, longitud, and intended application, which can range from a small craft project to the skin of an airplane.
Aluminium Sheet Size
The size of aluminum sheets varies widely depending on the application and manufacturer. Sin embargo, there are common standard dimensions and thicknesses.
Common Standard Sizes (Longitud x ancho):
In Imperial measurements:
4 feet x 8 pies (48″ x 96″)
4 feet x 10 pies (48″ x 120″)
5 feet x 10 pies (60″ x 120″)
Also smaller sizes like 12″ x 12″, 12″ x 18″, 18″ x 24″, 36″ x 72″ are available.
In Metric measurements:
1200 mm x 2440 mm
1200 mm x 3000 mm
1500 mm x 3000 mm
Other common metric sizes include 2000 X 1000 mm, 2500 X 1250 mm, 3000 X 1250 mm, 3000 X 1500 mm, and larger up to 4000 X 2000 mm or 12000 mm in length for plates.
Common Thicknesses:
Aluminum sheet thickness is often measured in millimeters (mm) or by gauge number (though gauge numbers can vary between materials).
Typical thicknesses range from:
Very thin: 0.2 mm to 0.5 mm (p.ej., for lighting fixtures, computer panels)
Common uses: 0.8 mm, 1.0 mm, 1.2 mm, 1.5 mm, 2.0 mm, 2.5 mm, 3.0 mm, 4.0 mm, 5.0 mm, 6.0 mm (often used for general construction, enclosures, vehicle bodies)
Thicker plates: 8.0 mm, 10.0 mm, 12.0 mm, up to 50 mm or even 500 mm for very thick plates (used in heavy machinery, marine components, recipientes a presión).
Important Considerations:
Alloy and Temper: The specific alloy (p.ej., 1050UNA, 3003, 5052, 6061, 7075) and temper (p.ej., H14, H32, T6) will affect the properties of the sheet, such as its strength, ductility, y resistencia a la corrosión.
…
