Adjusting the speed of a cone crusher, specifically the eccentric speed (the speed at which the mainshaft gyrates), is a critical operational parameter that impacts throughput, product gradation, power draw, and wear.
How to adjust the speed of cone crusher
Primary Methods of Speed Adjustment:
Variable Frequency Drive (VFD) / Variable Speed Drive (VSD):
How it works: A VFD controls the electrical frequency supplied to the crusher’s electric motor. By changing the frequency, the motor’s RPM changes, which in turn changes the speed of the crusher’s drive pulley and thus the eccentric speed.
Advantages:
Offers precise and continuous speed adjustment.
Can be adjusted while the crusher is running (though often done incrementally).
Allows for soft starting, reducing mechanical stress.
Can be integrated into plant automation systems.
Implementation: This is the most common and flexible method in modern plants. It requires installing a VFD unit appropriately sized for the crusher motor.
Changing Pulleys/Sheaves:
How it works: The crusher is driven by a motor via a belt and pulley system. The speed ratio is determined by the diameter of the motor pulley (drive sheave) and the crusher pulley (driven sheave).
Crusher Speed = Motor Speed × (Diameter of Motor Pulley / Diameter of Crusher Pulley)
To change the crusher speed, you would replace either the motor pulley or the crusher pulley (or both) with ones of different diameters.
To increase crusher speed: Use a larger motor pulley or a smaller crusher pulley.
To decrease crusher speed: Use a smaller motor pulley or a larger crusher pulley.
Disadvantages:
Requires downtime to change pulleys.
Offers stepped, not continuous, adjustment.
Belt tension needs to be readjusted.
More labor-intensive.
Implementation: This is an older method or used for significant, less frequent speed changes.
Factors to Consider When Adjusting Speed:
Product Gradation:
Higher Speed: Generally produces a finer product and more cubical particles. It increases the number of crushing actions per unit of time.
…
