In high-temperature and high-pressure environments such as steam systems, the choice of sealing material is crucial. Graphite sheets are widely recognized for their excellent thermal stability, chemical resistance, and sealing performance. However, not all graphite sheets are created equal. For sealing steam, flexible graphite sheets, particularly those reinforced with metal inserts, are generally considered the best option.
Which graphite sheet is best for sealing steam
Why Flexible Graphite for Steam?
High Temperature Resistance: Flexible graphite can withstand extremely high temperatures, often up to 550℃(1022℉) in air and up to 700℃ (1292℉) in steam or inert environments. This is crucial for steam applications which involve high temperatures and pressures.
Excellent Sealability: Graphite is highly compressible and conformable, allowing it to fill microscopic irregularities on flange surfaces and create a tight, leak-proof seal. It also has a low relaxation rate, meaning it maintains its seal over time, even with temperature and pressure fluctuations.
Chemical Resistance: It’s resistant to a wide range of chemicals, including most acids, alkalis, and organic compounds, making it versatile for various industrial applications.
Thermal Stability: Graphite gaskets exhibit excellent thermal stability, meaning they don’t embrittle, change structure, or lose components under high temperatures.
This prevents creep or flow of the gasket.
No Binders/Fillers: Pure flexible graphite sheets are typically made without organic or inorganic binders and fillers, which can degrade at high temperatures and compromise the seal.
Longevity: Due to its inherent properties, flexible graphite offers good long-term sealing performance and resistance to aging, although oxidation can occur at very high temperatures in oxygen-rich environments.
Types of Graphite Sheets Best for Steam:
Reinforced Flexible Graphite: This is often the preferred choice for steam due to the added strength and stability provided by the reinforcement. Common reinforcement materials include:
Stainless Steel Foil (Flat or Perforated): Provides enhanced mechanical strength, pressure resistance, and improved handling. Perforated (tanged) inserts create a strong mechanical bond with the graphite, preventing delamination.
Nickel or other metal inserts: Similar benefits to stainless steel, depending on specific application requirements.
…
